This is the COMPLETE Parts Reference List for the Brother Laser Printer HL-820 / HL-1020 / HL-1040 / HL-1050. Designed for the repair shops and individuals when ordering parts for their Brother Laser Printer HL-820 / HL-1020 / HL-1040 / HL-1050. This Manual describes and illustrates assemblies, subassemblies, and detail parts needed for service replacement. it Covers every part of your Brother Laser Printer HL-820 / HL-1020 / HL-1040 / HL-1050 inside and out. Tons of pictures and diagrams at your fingertips!
Models Covered:
=========
Brother Laser Printer HL-820
Brother Laser Printer HL-1020
Brother Laser Printer HL-1040
Brother Laser Printer HL-1050
Parts Reference List Contains:
=========
GENERAL DRAWING
MAIN PCB DRAWING (HL-820/1020/1040)
MAIN PCB DRAWING (HL-1050)
AC CORD / PACKING MATERIAL DRAWING
1. DRIVE UNIT
2. SCANNER UNIT
3. MP SHEET FEEDER
4. FIXING UNIT
5. COVERS
6-1. MAIN PCB <HL-820/1020>
6-2. MAIN PCB <HL-1040 OTHERS>
6-3. MAIN PCB <HL-1040 ISRAEL>
6-4. MAIN PCB <HL-1050 OTHERS>
6-5. MAIN PCB <HL-1050 ISRAEL>
7. PANEL SENSOR PCB
8. POWER SUPPLY PCB
9. HIGH VOLTAGE POWER SUPPLY
10. AC CORD
11. ACCESSORIES
12. PACKING MATERIALS
=========
