This is the COMPLETE Parts Catalog Manual for the Canon imageRUNNER C3100/C3100F/C3100i/C3100N/C3170/C3170F/C3170i/C2570/C2570F/C2570i Series. Designed for the repair shops and individuals when ordering parts for their Canon imageRUNNER C3100/C3100F/C3100i/C3100N/C3170/C3170F/C3170i/C2570/C2570F/C2570i Series. This Manual describes and illustrates assemblies, subassemblies, and detail parts needed for service replacement. it Covers every part of your Canon imageRUNNER C3100/C3100F/C3100i/C3100N/C3170/C3170F/C3170i/C2570/C2570F/C2570i Series inside and out. Tons of pictures and diagrams at your fingertips!
Models Covered:
=========
Canon imageRUNNER C3100 Series
Canon imageRUNNER C3100F Series
Canon imageRUNNER C3100i Series
Canon imageRUNNER C3100N Series
Canon imageRUNNER C3170 Series
Canon imageRUNNER C3170F Series
Canon imageRUNNER C3170i Series
Canon imageRUNNER C2570 Series
Canon imageRUNNER C2570F Series
Canon imageRUNNER C2570i Series
PARTS CATALOG MANUAL CONTAINS:
=========
A ASSEMBLY LOCATION DIAGRAM
001 ACCESSORIES
100 EXTERNAL COVERS, PANELS, ETC.
101 MACHINE FRONT PANEL
102 INTERNAL COMPONENTS 1
103 INTERNAL COMPONENTS 2
104 INTERNAL COMPONENTS 3
105 INTERNAL COMPONENTS 4
106 MACHINE REAR PLATE 1
107 MACHINE REAR PLATE 2
110 POWER CORD TERMINAL ASSEMBLY
130 CONTROL PANEL ASSEMBLY
140 RIGHT DOOR ASSEMBLY
141 PAPER FEEDER FRAME ASSEMBLY
145 RIGHT LOWER DOOR ASSEMBLY
190 ITB COOLING FAN ASSEMBLY
210 READER ASSEMBLY
250 MAIN DRIVE ASSEMBLY
260 PAPER DELIVERY DRIVE ASSEMBLY
261 MULTI DRIVE ASSEMBLY
300 CASSETTE (MIDDLE)
301 CASSETTE (LARGE)
310 PAPER PICK-UP ASSEMBLY (MIDDLE)
311 PAPER PICK-UP ASSEMBLY (LARGE)
315 MULTI FEED TRAY ASSEMBLY
350 PAPER DELIVERY ASSEMBLY
460 LASER SCANNER ASSEMBLY
535 TRANSFER BELT FRAME ASSEMBLY
630 ROTARY ASSEMBLY
640 DEVELOPING ASSEMBLY (BLACK)
641 DEVELOPING ASSEMBLY (YELLOW)
642 DEVELOPING ASSEMBLY (MAGENTA)
643 DEVELOPING ASSEMBLY (CYAN)
680 ATR SENSOR ASSEMBLY
780 TRANSFER CLEANING ASSEMBLY
810 FIXING ASSEMBLY
900 CONTROLLER BOX ASSEMBLY
910 MAIN POWER SUPPLY PCB ASSEMBLY
911 MAIN CONTROLLER POWER SUPPLY ASSEMBLY
930 DC CONTROLLER PCB ASSEMBLY
931 READER CONTROLLER PCB ASSEMBLY
980 H.V.TRANSFORMER PCB ASSEMBLY
990 FAX ASSEMBLY
991 SPEAKER ASSEMBLY
992 FAX BOARD PCB ASSEMBLY
