This is the COMPLETE Parts Catalog Manual for the Case IH Magnum 180, Magnum 190, Magnum 210, Magnum 225 – Small Frame Tractor Tier 4 (NA). Designed for the repair shops and individuals when ordering parts for their Case IH Magnum 180, Magnum 190, Magnum 210, Magnum 225 – Small Frame Tractor Tier 4 (NA). This Manual describes and illustrates assemblies, subassemblies, and detail parts needed for service replacement. it Covers every part of your Case IH Magnum 180, Magnum 190, Magnum 210, Magnum 225 – Tier 4 (NA) Small Frame Tractor inside and out. Tons of pictures and diagrams at your fingertips!
Models & serial numbers:
=========
MAGNUM 180 – SMALL FRAME TRACTOR TIER 4 (NA) – ZARH06086 AND AFTER
MAGNUM 190 – SMALL FRAME TRACTOR TIER 4 (NA) – ZARH06086 AND AFTER
MAGNUM 210 – SMALL FRAME TRACTOR TIER 4 (NA) – ZARH06086 AND AFTER
MAGNUM 225 – SMALL FRAME TRACTOR TIER 4 (NA) – ZARH06086 AND AFTER
PARTS CATALOG MANUAL CONTAINS:
=========
GENERAL & PICTORIAL INDEX
SERVICE & MAINTENANCE
ENGINE
MAIN GEARBOX & DRIVE
TRANSMISSION
FOUR WHEEL DRIVE SYSTEM
FRONT AXLE SYSTEM
REAR AXLE SYSTEM
HYDROSTATIC DRIVE
IMPLEMENT POWER TAKE OFF
BRAKES & CONTROLS
HYDRAULIC SYSTEMS
HITCHES, DRAWBARS & IMPLEMENT COUPLINGS
FRAMES AND BALLASTING
STEERING
WHEELS
CAB CLIMATE CONTROL
ELECTRICAL SYSTEMS
ACCESSORIES
PLATFORM, CAB, BODYWORK AND DECALS
=========
Model Specification: Case IH Magnum 180, Magnum 190, Magnum 210, Magnum 225 – Small Frame Tractor Tier 4 (NA)
Language: English
Total Pages: 1367
File Format: PDF
Requirements: Adobe PDF Reader
Compatible: All Versions of Windows & Mac, Linux OS, Iphone, Ipad, Android etc…
=========
