This is the COMPLETE Parts Manual for the Deutz F3M 2011F, BF3M 2011F, F4M 2011F, BF4M 2011F Engines. Designed for the repair shops and individuals when ordering parts for their Deutz F3M 2011F, BF3M 2011F, F4M 2011F, BF4M 2011F Engines. This Manual describes and illustrates assemblies, subassemblies, and detail parts needed for service replacement. it Covers every part of your Deutz F3M 2011F, BF3M 2011F, F4M 2011F, BF4M 2011F Engines inside and out. Tons of pictures and diagrams at your fingertips!
Models & Serial Number:
=========
Deutz F3M 2011F Engine
SN: 0654097 and Later
Deutz BF3M 2011F Engine
SN: 0590544 and Later
Deutz F4M 2011F Engine
SN: 0529127 and Later
Deutz BF4M 2011F Engine
SN: 0550682 and Later
This manual covers F3M 2011F engines with serial number 0654097 and later and BF3M 2011F engines with serial number 00590544 and later, and F4M 2011F engines with serial number 0529127 and BF4M 2011F engines with serial number 0550682 and later. The F3M 2011F and BF3M 2011F engines are used in SL4640 skid-steer loaders. The F4M 2011F and BF4M 2011F engines are used in SL4840, SL5640, and SL6640 skid-steer loaders.
