This is the COMPLETE Parts Manual for the Gehl 2140/2170 Mower Conditioner. Designed for the repair shops and individuals when ordering parts for their Gehl 2140/2170 Mower Conditioner. This Manual describes and illustrates assemblies, subassemblies, and detail parts needed for service replacement. it Covers every part of your Gehl 2140/2170 Mower Conditioner inside and out. Tons of pictures and diagrams at your fingertips!
Parts Manual Contains:
=========
Introduction
Standard Hardware Torque Specifications
Attaching Hardware Table
Decal Locations
Tongue (After SN11700-2140 & SN22200-2170)
Tongue (Before SN11701-2140 & SN22201-2170)
Trailer Frame, Leg & Pusharm
Pusharm & Hydraulics (After SN11700-2140 & SN22200-2170)
Pusharm & Hydraulics (Before SN11701-2140 & SN22201-2170)
Forming Chamber (After SN12000-2140 & SN22800-2170)
Forming Chamber (Before SN12001-2140 & SN22801-2170)
Header Frame & Conditioner Rollers
Wheel Assembly
Pitman Drive
Gearbox (AfterSN11700-2140 & SN22200-2170)
Gearbox (Before SNI1701-2140 & SN22201-2170)
Conditioner (Left Side)
Conditioner (Right Side)
Reel Variable Drive
Pitman & Wobble Arm Drive
Reel
Sickle & Guards, 2140
Sickle & Guards, 2170
PTO Tower (After SN11700-2140 & SN22200-2170)
PTO Tower With 092009 CV Joint Kit (Before SN11701-2140 & SN22201-2170)
PTO Tower (Before SN11701-2140 & SN22201-2170)
Telescoping Drive (Tower To Tractor)(After SN11700-2140 & SN22200-2170)
Telescoping Drive (Tower To Tractor)(Before SN11701-2140 & SN22201-2170)
Hitchjacks
Options & Accessories
Mechanical Tongue Positioner
Hydraulic Tongue Positioner
Center Skid Shoe & Cutter Bar Wear Plate
Tall Crop Divider
Narrow Windrow Guides
Numerical Index
=========
Model Specification: Gehl 2140/2170 Mower Conditioner
Language: English
Total Pages: 48
File Format: PDF
Requirements: Adobe PDF Reader
Compatible: All Versions of Windows & Mac, Linux OS, Iphone, Ipad, Android etc…
=========
